- Bezerk Litesabre 2.0 -

Track : England Park Queensland Australia - Long Short Layout.
Temp - 23C
10.5T Pro 10
Queensland Titles 2022
TQ & 1st
Fastest Lap 19.01 Q3
19 Laps 6:14.893 Q3

Front Suspension
Xray US Graphite 18-20
Long King pins with 20k oil
AE 0.20 Dynamic Long front springs - Kingpins stacked with shims until touching.
Standard 0 arm track
AE 10L2 Inline knuckles flipped left to right.
Liunsford Titanium Axles
2mm bump steer shims with Xenon raised Alu. Balls
Short front wheelbase
Lunsford steering turnbuckles
Xray Servo Saver lower holes
Pitlane prototype Mini servo mounted low so flush with base of front chassis plate
Xray side links with Alu. 5.8mm balls

Short side tubes with 80k oil (Outer ball on 3rd inner hole. Upper plate on outer holes - No shims)
Dual side springs
Gravity Purple and Black Race Opt MTS Linear and RAS Short Touring shocks used. 4x1.1mm hole - 500cst oil Race Opt Yellow/Grey Linear Spring
MTS chassis centre post used as extender.
15mm thrnbuckle into eyelet and loctite into extender.

7.5mm rear ride height
7mm effective front ride height (9mm actual measured to chassis plate) Hiro Seiko Titanium and Alu. Screws/nuts used throughout.

Tyres used
Contact 28R 30F (use 25R)
Matrix 25R 35f Quali
BSR PinkR- x2 PinkF

Electronics
Team Powers Electronics
Radon V4 - V5 firmware
PS 2s Booster Cap V2
Actinium V4 10.5 - Spec Rotor. 42 to 47 can timing all weekend
ESC Setup

Pitlane 5mm bullets
Pitlane Sensor Cable
Phat Dad ESC Noise cap.
Intellect Shorty Lipo 20g weight under battery.
5g each side of servo.
Flysky Noble

Protoform Swift 235
Reproduced by Outsiders RC🇦🇺
Mounted neutral
Shu gu stiffen rear fins/wing with full cut out rear wing window.
Polycarb Side stiffeners.
